Andriod OS Mobile Smart Industrial PDA Pocket PC Computer with Built-in GPS,Bluetooth

Name: Andriod OS Mobile Smart Industrial PDA Pocket PC Computer with Builtin GPSBluetooth
Brand: Speedata
Price: 1 USD

Best Andriod OS Mobile Smart Industrial PDA Pocket PC Computer with Built-in GPS,Bluetooth wholesale

Brand Name : Speedata

Model Number : KT50

Certification : ISO9001/CE/FCC/IP65/1.5M Drop

Place of Origin : China Mainland

MOQ : 1 unit

Payment Terms : Western Union, MoneyGram, T/T, L/C

Supply Ability : 10000 unit/ month

Packaging Details : Speedata POS Fingerprint Reader conventional packing-1pcs;usb data cable-1pcs;charger-1pcs;protection cover-1pcs;hand strap-1pcs.

Product Name : Andriod OS Mobile Smart Industrial PDA

OS : Android 6.0

CPU : Cortex-A53 1.3GHz Quad-core

RAM : 2GB

ROM : 16GB

Camera : Rear Camera 8MP

Focus Mode : Auto Focus

Flash : Support single color LED flash

Display : 5.0" IPS LCD

Resolution : 720P (1280*720)

Battery : 7.4V 19.24WH

Charging : DC dedicated charger 9V/1.2A

Fingerprint Scanner : Crossmatch Capacitive Fingerprint Scanner TCS1G (with FBI, FIPS-201 ,ISO19794,ANSI,WSQ)

Barcode Scanner : 1D： Honeywell N4313 ; 1D/2D：Honeywell N6603

Thermal Printer : Roll width ±58mm, roll thickness 40mm

IC/MSR : ISO 7816, GSM 11-11, EMV4.2 and EMV 2000

Contact Now

5.5'' Touch Capacitive Screen Portable Data Collector Android 5.1 Smart IC Card Reade

Products Introduction

Rugged and durable with high performance

SD55UHF Handheld RFID Reader provides high performance UHF RFID Reading/Writing Capability. It is designed to support EPC C1 GEN2 / ISO18000-6C protocol, and equipped with cost-effective UHF module that covers frequency ranges for most areas. This versatile device can also be configured with class leading high performance 1D/2D barcode scanning and a variety of wireless connections such as Bluetooth, 4G, and WiFi.

Prducts Features:

◆ 5-inch HD high-resolution 720p display to meet outdoor operational requirements;Support full Netcom system;

◆ Flexible circuit design to provide customized and customized services to meet the needs of different users;

◆ The device integrates multiple data collection functions and wireless communication in one,with reliable performance and simple operation.

◆ IP65 protection level,high unity of performance and durability is achieved;

◆ Innovative design that conforms to ergonomic design and user friendly interface can maximize productivity;

◆ Explosion-proof products, widely used in petroleum and petrochemical industry

Specifications of KT50 Mobile Handheld Smart Card Reader Device

KT50 Basic Parameters
OS	Android 6.0
CPU	Cortex-A53 1.3GHz Quad-core
RAM	2GB
ROM	16GB
Expansion	Micro SD (TF) card slot up to 128GB
Keypad	5 side buttons: 2 volume buttons,2 function buttons(1 left and right),1 power button
Keypad	LED Keypad backlight
Notification	Sound/vibration/LED prompt
Audio	Built-in speaker
Interface	1MicroSD/TF slot card; 2SIM card slots; 1PSAM Slot; 1Micro USB; 1DC Power Jack; 13.5mm Audio Jack
Interface	RS-232/485 (Optional)
Dimentions	175mm76mm28mm (without expansion standard size)
Weight( with battery)	390g
Camera
Camera	Rear camera 13MP
Focus mode	Auto Focus
Flash	Support single color LED Flash
Display
Display	5.0" IPS LCD
Resolution	720P (1280*720)
Touch Panel	5-point capacitive touch screen
Backlight	LED backlight
Power
Battery	7.4v 19.24WH
Charging	DC dedicated charger 9V/1.2A
Communication
Network	Dual SIM Dual Standby, 4G Full Netcom
Bluetooth	V2.1+ EDR/ V3.0+ HS/ V4.0 BLE
WLAN	WIFI 802.11 b/g/n/a 2.4G/5G
WWAN	FDD-LTE B1/B3/B5/B7 or B1/B4/B8/B13 TDD-LTE B38/B39//B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0
GPS	GPS, AGPS, BEIDOU,Positioning accuracy < 10 meters,Positioning time < 40s
Performance
Operation Temperature	-20℃ ~50℃
Operation Temperature	-20℃ ~50℃
Storage Temperature	-45℃ ~+60℃
Humidity	5%~95%(No condensation)
Sealing	IP65
Drop Test	In the operating range, 6 sides can withstand the impact of 1.5 meters drop to the concrete floor
Tumble Test	6 contact surfaces rolling for 1000 times/ 0.5M
ESD	±15kV Air Discharge, ±8kV Contact Discharge
Certificate	CCC,CTA
Extensibility
RFID Reader	1. HF(RC663) :13.56MHz reader and writer,ISO 14443A/B, ISO 15693 Reading distance: 0cm-5cm
	2. NFC (PN547) : 13.56MHz reader and writer,ISO 14443A/B, ISO 15693 Reading distance: 0cm-5cm
	3. LF : 134.2KHz, ISO 11784/11785, FDX-B/HDX; 125KHz Reading distance: 0cm-10cm
	4. UHF : Impinj R2000 860-960MHz ISO18000-6C (EPC Gen2) Reading distance Max 5m; UQMX 860-960MHz ISO18000-6C (EPC Gen2) Reading distance Max 3m
Barcode Scanner	1D: Honeywell N4313
Barcode Scanner	1D/2D:Honeywell N6603
Reading Distance	5cm-40cm according to barcode model and size
PSAM	Support
Sensor	Seomagnetism, Acceleration, Light Perception Distance,Berometer(optional), Pyroscope (optional)

Products Details

Andriod OS Mobile Smart Industrial PDA Pocket PC Computer with Built-in GPS,Bluetooth

About Speedata

Speedatagroup ——10 Years Original Manufacturer of IOT Mobile Computer.

Beijing Speedata Technology Co., Ltd. (Stock Code: 832442 ), founded in 2008, is a provider of IOT (Internet of Things) Solutions and OEM/ODM Manufacturer of Mobile Computing Handheld PDA Terminals for a wide range of industries as a Golden Manufacturer with OEM/ODM services .

For the past 8 years, Speedata has been rapidly growing as a high-tech enterprise of R&D, production and sales, and furthermore, having extensive application experience in the IOT field.
..1). We are headquartered in Beijing, with branch offices in Shanghai, Shenzhen and Dalian, as well as India.
..2). We have 2 factories, one is in Beijing and another is in Tianjing.
..3). We are also in successful cooperation with Foxconn.

Speedata Handheld Terminal Devices are adopted with flexible configuration open platform and mainstream embedded Operating Systems like Android, Windows CE or Windows Mobile. the terminal integrated 1D/2D barcode scanner, LF/HF/UHF RFID reader, fingerprint reader, thermal printer, MSR, PSAM, 2.4G communication and IR meter reading function modules etc.
Our products has provides multi-applications and prospects among a myriad of industries, like:

1.Logistics & Express
2.Transportation
3.Electric Meter Readings
4.Network Community Management
5. Storage & Distribution
6.Petrochemical Inspection
7.Geomatics & Surveying
8.Product Tracking
9.Health & Pharmaceutical Industry
10.Mobile Police Service
11.Tobacco Logistics
12.Fixed-assets Management
13.Surveying and Mapping
14.Agriculture
15.Water Conservation
16.Animal Tracking & Research
17.Retail Chain
